2026 Z125

Engine Type

Liquid-cooled, 4-stroke Single cylinder

Displacement

125cc

Bore x stroke

58 x 47.2 mm

Compression ratio

11.7:1

Valve/Induction system

DOHC, 4 valves

Fuel system

Fuel injection: Ø 28 mm x 1

Ignition

Digital

Starting

Electric

Lubrication

Forced lubrication, wet sump

CO2 Emission

61 g/km

Maximum Power

11 kW {15 PS} / 10,000 rpm

Maximum torque

11.7 N•m {1.2 kgf•m} / 7,700 rpm

Transmission

6-speed

Final Drive

Chain

Clutch

Wet multi-disc

Frame type

Tubular diamond, steel

Rake/Trail

Trail: 90mm

Wheel travel

Front: 110 mm | Rear: 112 mm

Seat Height

815mm

Curb Mass

147 kg

Ground Clearance

185 mm

Dimensions (L x W x H)

1,935 x 740 x 1,015 mm

Wheelbase

1,330 mm

Fuel Capacity

11 Litres

Suspension front

37 mm telescopic fork

Suspension Rear

Uni-Trak, gas-charged shock with adjustable preload

Brakes Front

Single 290 mm petal disc. Caliper: Dual piston

Brakes Rear

Single 220 mm petal disc. Caliper: Dual piston
