Engine
Engine Type
Liquid-cooled, 4-stroke In-Line Four
Displacement
1099cc
Bore x stroke
77 x 59 mm
Compression ratio
11.8:1
Valve/Induction system
DOHC, 16 valves
Fuel system
Fuel injection: Ø 38 mm x 4
Ignition
Digital
Starting
Electric
Lubrication
Forced lubrication, wet sump
CO2 Emission
128 g/km
Performance & Transmission
Maximum Power
99.0 kW {135 PS} / 9,000 rpm
Maximum torque
112 N•m {11.4 kgf•m} / 7,600 rpm
Transmission
6-speed, return
Final Drive
Chain
Clutch
Wet multi-disc, manual
Frame & Dimensions
Frame type
Twin-tube, aluminium
Rake/Trail
27.0°/106 mm
Wheel travel
Front: 150 mm | Rear: 152 mm
Steering angle
34° / 34°
Seat Height
840 mm
Curb Mass
257 kg
Ground Clearance
150 mm
Dimensions (L x W x H)
2,270 x 950 x 1,490 (1,530 high position screen) mm
Wheelbase
1,520 mm
Fuel Capacity
21 litres
Brakes & Suspension
Suspension front
ø43 mm inverted fork with rebound damping (right-side) and spring preload adjustability
Suspension Rear
Horizontal Back-link, gas-charged, with rebound damping and remote spring preload adjustability
Brakes Front
Dual semi-floating 310 mm petal discs. Caliper: Dual radial-mount, monobloc, opposed 4-piston
